The World's first Tissue level implant with a specialized
coating designed to maximize gingival esthetic
integration via coloring of the implant neck.

What is your favorite color?

Dentalis Tissue level implants bring together an inventive endosteal design and optimal stability to open a wide range of new clinical possibilities.

What is your favorite color?

Dentalis Tissue level implants bring together an inventive endosteal design and optimal stability to open a wide range of new clinical possibilities.

Pink Tissue Level Implant

Pink Tissue level Vi features a transmucosal collar for one-stage procedures, attach connective tissue and creates a biological seal around the implant. are available in 4 diameters:3.25, 3.75, 4.2, 5.0

The optical phenomenon of peri-implant soft tissue. Preferred implant neck color to improve soft tissue esthetics

Horizontal grooves produced by micro-machining impedes epithelial down growth on titanium implants.

Micro threads provide enhanced initial stability and increases contact area to crestal bone, which will enhance osseointegration at the crestal bone level.

The presence of two spiral channel, self-tapping cutting threads facilitates implant placement and enhance primary stability

Sharp threads and spiral deepening from cervical to apical region, and improved cutting ability, with better bone to implant contact for better primary stability

Grooved threads enhance bone stabilization during primary stabilization and increase the amount of bone to implant contact, enhancing osseointegration.

optimized threadform

Anatomically tapered implant body has proprietary reverse buttress threads with wide flat leading edges for increased stability.

Restorative ease

The Pink Tissue Versatile implant offers a conical internal hex connection with 45° central hole.

DESIGNED FOR IMMEDIATE PROTOCOLS

  • Fully tapered implant with deep threads and grove threads designed for optimized primary stability combined with the predictability of Tissue Level Implant
  • A narrow implant diameter option, 3.25 mm for all indications.

PERI-IMPLANT HEALTH PRESERVATION

  • Reduced risk of nesting bacteria
  • Preferred implant neck color to improve soft tissue esthetics

REAL CONFIDENCE

  • USA precision and quality Titanium Grade 23 material and BAS® surface



SIMPLICITY AND EFFICIENCY
  • A one-stage process with restoration at soft-tissue level allows you to reduce chair time .
  • Ease of restoration even in the posterior region, with the same type of restoration of the Bone level implants
  • Highly efficient treatment protocol thanks to straightforward conventional and digitally integrated workflows
2 Pink Dentalis implant
Dentalis Pinkasambly all_4_

The pink tissue versatile implant neck combines superior gingival aesthetics and high primary stability, improved placement,
and temporization, which is particularly beneficial in
aesthetically demanding cases.

REFERENCES:

1.Bittner N, Schulze-Späte U, Cleber S, Da Silva J, Kim D, Tarnow D, Ishikawa-Nagai S, Gil M. Comparison of Peri-implant Soft Tissue Color with the Use of Pink-Neck vs Gray Implants and Abutments Based on Soft Tissue Thickness:
A 6-Month Follow-up Study. Int J Prosthodont. 2020Jan/Feb;33(1):29-38.

2. Gil M, Ishikawa-Nagai S, Elani H, Da Silva J, Kim D, Tarnow D, Schulze-Späte U, Cleber S, Bittner N. Comparison of the Color Appearance of Peri-implant Soft Tissue with Natural Gingiva Using Anodized Pink-Neck Implants and Pink Abutments: A Prospective Clinical Trial. Int J Oral Maxillofac Implants. 2019 May/June;34(3):752–758.

3.Gil M, Ishikawa-Nagai S, Elani H. A prospective clinical trial to assess the optical efficacy of pink neck implants and pink abutments on soft tissue aesthetics. J Esthet Restor Dent. 2017;29(6):1-7.38.

The pink tissue versatile implant neck combines superior gingival aesthetics and high primary stability, improved placement, and temporization, which is particularly beneficial in aesthetically demanding cases.

REFERENCES:

1.Bittner N, Schulze-Späte U, Cleber S, Da Silva J, Kim D, Tarnow D, Ishikawa-Nagai S, Gil M. Comparison of Peri-implant Soft Tissue Color with the Use of Pink-Neck vs Gray Implants and Abutments Based on Soft Tissue Thickness:
A 6-Month Follow-up Study. Int J Prosthodont. 2020Jan/Feb;33(1):29-38.

2. Gil M, Ishikawa-Nagai S, Elani H, Da Silva J, Kim D, Tarnow D, Schulze-Späte U, Cleber S, Bittner N. Comparison of the Color Appearance of Peri-implant Soft Tissue with Natural Gingiva Using Anodized Pink-Neck Implants and Pink Abutments: A Prospective Clinical Trial. Int J Oral Maxillofac Implants. 2019 May/June;34(3):752–758.

3.Gil M, Ishikawa-Nagai S, Elani H. A prospective clinical trial to assess the optical efficacy of pink neck implants and pink abutments on soft tissue aesthetics. J Esthet Restor Dent. 2017;29(6):1-7.38.

Dentalis Surface:

Surface roughness is achieved from “grit-blasting,” using a unique combination of the HA particles (soluble) with different sizes of grains and hardness. This process creates optimal structural roughness on the surface and enables the incorporation of biocompatible particles (such as HA and TCP). Dentalis Roughness is measured with an average roughness (Ra), while the most commonly used parameter for describing roughness is calculated in microns. The rough surfaces produced by grit-blasting have irregular geometries with Ra value of 3.3 μm, which is considered optimal for the osseointegration process (1).

Raw Material:

All Dentalis implants are made of Ti 6Al-4V ELI that is a higher-purity (“extra-low interstitial”) version of Ti 6Al-4V, with lower specified limits on iron and the interstitial elements C and O. It is an alpha + beta alloy .Ti 6Al-4V ELI may be considered in any biomedical application, particularly for implantable components, because of its biocompatibility, good fatigue strength, and low modulus. Ti 6Al-4V ELI has been the material of choice due to its excellent biocompatibility. The ELI grade has superior damage tolerance (fracture toughness, fatigue crack growth rate) and better mechanical properties compared to standard grade Ti 6Al-4V.

Implant Range:

-
4mm
5mm
6.5mm
8mm
10mm
11.5mm
13mm
16mm
18mm
3.25mm
-
-
-
-
123210
123211
123213
123216
-
3.75mm
-
-
-
123708
123710
123711
123713
123719
123718
4.2mm
124204
124205
124206
124208
124210
124211
124213
124216
124218
5.0mm
125004
125005
125006
125010
125011
125013
-
-

Procedures recommended by DENTALIS cannot replace the judgment and professional experience of the surgeon.

DENTALIS_equicrestal-and-subcrestal-dental-implants-a-histologic-and-histomorphometric-evaluation-_optimized (1)

For over two decades, Dentalis has led implant dentistry into a new era of attainability and aesthetics.

The pink tissue versatile implant neck combines superior
gingival aesthetics and high primary stability,
improved placement, and temporization,
which is particularly beneficial in
aesthetically demanding cases.

REFERENCES:

1.Bittner N, Schulze-Späte U, Cleber S, Da Silva J, Kim D, Tarnow D, Ishikawa-Nagai S, Gil M. Comparison of Peri-implant Soft Tissue Color with the Use of Pink-Neck vs Gray Implants and Abutments Based on Soft Tissue Thickness:
A 6-Month Follow-up Study. Int J Prosthodont. 2020Jan/Feb;33(1):29-38.

2. Gil M, Ishikawa-Nagai S, Elani H, Da Silva J, Kim D, Tarnow D, Schulze-Späte U, Cleber S, Bittner N. Comparison of the Color Appearance of Peri-implant Soft Tissue with Natural Gingiva Using Anodized Pink-Neck Implants and Pink Abutments: A Prospective Clinical Trial. Int J Oral Maxillofac Implants. 2019 May/June;34(3):752–758.

3.Gil M, Ishikawa-Nagai S, Elani H. A prospective clinical trial to assess the optical efficacy of pink neck implants and pink abutments on soft tissue aesthetics. J Esthet Restor Dent. 2017;29(6):1-7.38.

Contacts

The combination of innovative surface technology with 344% stronger bone reduces marginal bone loss and provides for a higher BIC%, decreasing the risk of peri-implant disease. The enhanced deep thread simplifies the insertion and allows for high primary stability.

Now is the time to learn about the future in implant dentistry with neck designs combining a smooth surface in the trans-mucosal area coated with a micro-rough surface inside the bone.

This is the first dental implant to combine the concept of tissue-level
implants with an anti-bacterial coating on the implant neck, preventing
peri-implant disease and providing predictable results you can trust.

The coating can inhibit attachment of P. gingivalis and promote
osteoblast adhesion on the titanium used for implants

Now is the time to learn about the future in implant dentistry with neck designs combining a smooth surface in the trans-mucosal area coated with a micro-rough surface inside the bone.

This is the first dental implant to combine the concept of tissue-level implants with an anti-bacterial coating on the implant neck, preventing peri-implant disease and providing predictable results you can trust.

The coating can inhibit attachment of P. gingivalis and promote
osteoblast adhesion on the titanium used for implants

asaambly_16_18with-short_optimized
